BM Series (Golf Cart / Electric Vehicle)

Home >
Products >

“The Ultra Power of Newmax Lead-Acid Battery”

Taking advantage of our proprietary DenseMax™ casting technology for the flooded type deep cycle batteries, BM series are built to provide ultra-long life and durability and tested to survive the mountainous golf courses with slopes and hills in South Korea.

MossGuard™ anti-moss post processing technology adds to the longevity and durability of our BM series batteries.

DenseMax™ Grid casting technology
MossGuard™ anti-moss post plate processing
Flooded Type Deep Cycle
Micro-porous corrosion resistant PVC separator

BM Series Battery Range Specifications

※ 좌, 우로 스와이프하면 내용을 확인할 수 있습니다.

Battery Type	(V)	Nominal Capacity (AH)			Exterior Dimension								Liauid Amount (ℓ)	Weight (KG)	Terminal Type
		20HR	5HR	75A (min)	Length		Width		Height		Total Height
		20HR	5HR	75A (min)	(mm)	(inch)	(mm)	(inch)	(mm)	(inch)	(mm)	(inch)
BM 6225	6	225	185	115	260	10.24	183	7.20	247	9.72	279	10.98	5.7	28.6	Standard
BM 6240	6	240	195	132	260	10.24	183	7.20	247	9.72	279	10.98	5.4	30.7	Standard
BM 8190	8	190	155	90	260	10.24	183	7.20	247	9.72	279	10.98	5.2	31.6	Standard
BM 8240	8	240	195	110	260	10.24	183	7.20	283	11.14	317	12.48	6.2	37.6	Standard
BM 8260	8	260	200	120	260	10.24	182	7.17	295	11.61	338	13.31	7.2	39.5	Standard
BM 12165	12	165	135	70	331	13.03	183	7.20	247	9.72	279	10.98	6.8	39.6	Standard

TERMINAL(mm)

※ 좌, 우로 스와이프하면 내용을 확인할 수 있습니다.

Type	A	B	C	D	E	F	G	H	I	J	K	L	M	N	O
(A)	4.75	6.30	12.00	15.00	15.00	11.50	4.50	11.50	13.50	13.50	M6	M6	M6	M8	M8
(B)	0.80	0.80	6.50	6.30	6.30	5.00	11.50	5.25	5.00	5.00	14.00	15.50	17.50	21.00	22.00
(C)	8.60	8.60	2.30	5.00	7.00	5.00	5.00	5.00	5.00	6.00
