PNGB Series

PNGB Series (2V block For UPS, Deep Cycle Gel)

Home >
Products >

"The Ultra Power of Newmax Lead-Acid Battery"

The PNGB series has a completely sealed gas-recombining structure which has a relatively long life. It is available in various capacities and dimensions.
This series is fit for both floating and deep cycle service, such as UPS, telecommunication and lighting systems. They are usable in a wide temperature range, from -20°C to 50°C and can be used in various services including high-rate discharge.

DenseMax™ Grid Technology

Proprietary grid casting technology that condenses the lead grain in the grids increasing the density by 50% compared to a conventional gravity casting method. Higher density grids enable prolonged battery life even in the most severe operating environments.
ThixoPure™ GEL Technology

Application of refined pure thixotropic colloidal silica GEL technology to battery electrolyte has greatly increased the cycle life by both preventing plate stratification and providing extra temperature protection against heat and cold. We are the first Korean company to successfully commercialize the GEL technology in the VRLA battery industry.
FlexSealing™ Anti Explosion Filter

Patent pending proprietary cap filtering and sealing technology. Battery cell caps are sealed simultaneously using specially designed o-rings and explosion filters to prevent leakage and gassing more effectively than ever before.
ActiveCarbon™

In every Newmax battery, proprietary micro carbon additive is used in the active material for both positive and negative plates to improve acceptance and cycle endurance. ActiveCarbon™ works to strengthen charge pathways to improve performance consistency and enhance performance at partial state of charge (PSoC) environment.
Thermal Protection Heat Protection Case

Specially formulated heat and flame resistant polypropylene case material is used to effectively block ambient heat thus preventing heat related malfunctions such as thermal runaway. This proprietary high rigidity case material has heat deflection rating of 140°C and complies to RoHS Compliant EU Directive 2002/95/EC. Additional UL94-V0 protection also available.

2V PNGB Series Battery Range Specifications

※ 좌, 우로 스와이프하면 내용을 확인할 수 있습니다.

Battery Type	(V)	Nominal Capacity (AH)				Dimension								Weight		Terminal Type
		10HR	5HR	3HR	1HR	Length		Width		Height		T.Height		Approx.		Terminal Type
		Final V.P.C				(mm)	(inch)	(mm)	(inch)	(mm)	(inch)	(mm)	(inch)	(Lb)	(kg)	(S)	(O)
		(1.80)	(1.75)	(1.70)	(1.60)	(mm)	(inch)	(mm)	(inch)	(mm)	(inch)	(mm)	(inch)	(Lb)	(kg)	(S)	(O)
PNGB 21000	2	100	90	83	66	106	4.17	170	6.69	326	12.83	364	14.33	17.4	7.9	I	P
PNGB 21200	2	120	108	99	79	106	4.17	170	6.69	326	12.83	364	14.33	20.5	9.3	I	P
PNGB 21500	2	150	135	124	99	106	4.17	170	6.69	326	12.83	364	14.33	22.9	10.4	I	P
PNGB 22000	2	200	180	166	131	106	4.17	170	6.69	326	12.83	364	14.33	27.6	12.5	I	P
PNGB 22500	2	250	225	207	164	195	7.68	170	6.69	326	12.83	364	14.33	35.5	16.1	I	P
PNGB 23000	2	300	270	248	197	195	7.68	170	6.69	326	12.83	364	14.33	41.9	19.0	I	P
PNGB 24000	2	400	260	414	263	195	7.68	170	6.69	326	12.83	364	14.33	51.8	23.5	I	P
PNGB 25000	2	500	450	414	329	289	11.38	171	6.73	326	12.83	364	14.33	66.1	30.0	I	P
PNGB 26000	2	600	540	497	394	289	11.38	171	6.73	326	12.83	364	14.33	76.1	34.5	I	P
PNGB 27000	2	700	630	580	460	382	15.04	171	6.73	326	12.83	364	14.33	91.7	41.6	I	P
PNGB 28000	2	800	720	662	526	382	15.04	171	6.73	326	12.83	364	14.33	101.9	46.2	I	P
PNGB 29000	2	900	810	745	591	471	18.54	171	6.73	326	12.83	364	14.33	119.7	54.3	I	P
PNGB 210000	2	1000	900	828	957	471	18.54	171	6.73	326	12.83	364	14.33	131.0	59.4	I	P
PNGB 212000	2	1200	1080	994	788	471	18.54	171	6.73	326	12.83	364	14.33	143.7	65.2	I	P
PNGB 214000	2	1400	1260	1150	920	472	18.58	335	13.19	329	12.95	366	14.41	188.5	85.5	J
PNGB 216000	2	1600	1440	1292	1051	472	18.58	335	13.19	329	12.95	366	14.41	215.2	97.6	J
PNGB 218000	2	1800	1620	1458	1178	472	18.58	335	13.19	329	12.95	366	14.41	235.2	107	J
PNGB 220000	2	2000	1800	1658	1314	472	18.58	335	13.19	329	12.95	366	14.41	253.1	115	J

TERMINAL(mm)

※ 좌, 우로 스와이프하면 내용을 확인할 수 있습니다.

Type	A	B	C	D	E	F	G	H	I	J	K	L	M	N	O
(A)	4.75	6.30	12.00	15.00	15.00	11.50	4.50	11.50	13.50	13.50	M6	M6	M6	M8	M8
(B)	0.80	0.80	6.50	6.30	6.30	5.00	11.50	5.25	5.00	5.00	14.00	15.50	17.50	21.00	22.00
(C)	8.60	8.60	2.30	5.00	7.00	5.00	5.00	5.00	5.00	6.00
